COLUMBIA 24 CHALLENGER
Built by Glass Laminates/Columbia Yachts (USA)
• Designed by J. McGlasson
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Fin Keel
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1962
Last Built:
1968
Number Built:
534
Dimensions
Length Overall (LOA):
7.42 m
Length Waterline (LWL):
5.49 m
Beam:
2.44 m
Draft (Max):
1.01 m
Weight & Ballast
Displacement:
1,783 kg
Ballast:
816 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
12.58 m²
Mainsail Area:
14.17 m²
Total Sail Area (calculated):
26.75 m²
Sail Area (reported):
26.76 m²
I (Fore Triangle Height):
9.17 m
J (Fore Triangle Base):
2.74 m
P (Mainsail Hoist):
8.23 m
E (Boom Length):
3.44 m
Engine & Systems
Performance Ratios
Hull Speed:
5.69 knots
SA/Displacement (Calculated):
18.20
SA/Displacement (Reported):
18.55
Ballast/Disp Ratio:
45.80%
Displacement/Length:
300.83
Comfort Ratio:
19.12
Capsize Screening:
2.03
S-Number:
1.85
Notes
The COLUMBIA CHALLENGER is a raised deck version of the COLUMBIA 24. The COLUMBIA 24, COLUMBIA CONTENDER 24, and COLUMBIA CHALLENGER 24, all derive from the earlier ISLANDER 24.
