470
Built by Various
• Designed by André Cornu
General Information
Hull Type:
Centerboard Dinghy
Rigging Type:
Fractional Sloop
Construction:
FG
First Built:
1963
Dimensions
Length Overall (LOA):
4.70 m
Length Waterline (LWL):
4.44 m
Beam:
1.68 m
Draft (Max):
0.97 m
Draft (Min):
0.15 m
Weight & Ballast
Displacement:
122 kg
Sail Plan
Sail Area (reported):
12.73 m²
Engine & Systems
Performance Ratios
Hull Speed:
5.12 knots
SA/Displacement (Reported):
52.65
Displacement/Length:
38.75
Comfort Ratio:
2.89
Capsize Screening:
3.41
Notes
2 person centerboard class with trapeze.
