ALLMAND 35 PILOT HOUSE
Built by Allmand Boats Inc. (USA)
• Designed by W.H. Scott/T.R. Allmand
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Cutter
Construction:
FG (solid)
First Built:
1981
Last Built:
1985
Dimensions
Length Overall (LOA):
10.59 m
Length Waterline (LWL):
8.59 m
Beam:
3.56 m
Draft (Max):
1.50 m
Weight & Ballast
Displacement:
5,443 kg
Ballast:
1,950 kg
Sail Plan
Foresail Area:
27.79 m²
Mainsail Area:
21.08 m²
Total Sail Area (calculated):
48.87 m²
Sail Area (reported):
48.87 m²
I (Fore Triangle Height):
13.21 m
J (Fore Triangle Base):
4.21 m
P (Mainsail Hoist):
11.06 m
E (Boom Length):
3.81 m
Engine & Systems
Engine Make:
Universal
Engine Type:
Diesel
Engine Power:
30 HP
Fuel Capacity:
151 L
Water Capacity:
473 L
Performance Ratios
Hull Speed:
7.11 knots
SA/Displacement (Calculated):
15.79
SA/Displacement (Reported):
16.11
Ballast/Disp Ratio:
35.83%
Displacement/Length:
239.65
Comfort Ratio:
23.33
Capsize Screening:
2.04
S-Number:
2.19
Notes
Shallow draft: 3.92'.
