CHRYSLER 22
Built by Chrysler Marine
• Designed by Halsey Herreshoff
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Swing Keel
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1975
Last Built:
1978
Dimensions
Length Overall (LOA):
6.71 m
Length Waterline (LWL):
5.79 m
Beam:
2.36 m
Draft (Max):
1.37 m
Draft (Min):
0.59 m
Max Height:
8.08 m
Weight & Ballast
Displacement:
1,361 kg
Ballast:
374 kg
Sail Plan
Foresail Area:
11.24 m²
Mainsail Area:
8.23 m²
Total Sail Area (calculated):
19.47 m²
Sail Area (reported):
18.77 m²
I (Fore Triangle Height):
8.38 m
J (Fore Triangle Base):
2.68 m
P (Mainsail Hoist):
7.10 m
E (Boom Length):
2.32 m
Engine & Systems
Performance Ratios
Hull Speed:
5.84 knots
SA/Displacement (Calculated):
15.85
SA/Displacement (Reported):
15.58
Ballast/Disp Ratio:
27.50%
Displacement/Length:
195.26
Comfort Ratio:
15.23
Capsize Screening:
2.15
S-Number:
2.66
Notes
When TMI first bought the molds, they called it the C-22. Later the T-22 Sandpiper.
