CAVALIER 28
Built by Cavalier Yachts (AUSTRALIA)
• Designed by Laurie Davidson
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Fin w/transom hung rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1975
Number Built:
100
Dimensions
Length Overall (LOA):
8.53 m
Length Waterline (LWL):
7.62 m
Beam:
2.82 m
Draft (Max):
1.60 m
Weight & Ballast
Displacement:
4,082 kg
Ballast:
1,237 kg
Sail Plan
Foresail Area:
18.70 m²
Mainsail Area:
14.63 m²
Total Sail Area (calculated):
33.33 m²
Sail Area (reported):
33.35 m²
I (Fore Triangle Height):
10.67 m
J (Fore Triangle Base):
3.51 m
P (Mainsail Hoist):
9.14 m
E (Boom Length):
3.20 m
Engine & Systems
Engine Make:
Bukh
Engine Type:
Diesel
Performance Ratios
Hull Speed:
6.70 knots
SA/Displacement (Calculated):
13.05
SA/Displacement (Reported):
13.32
Ballast/Disp Ratio:
30.30%
Displacement/Length:
257.14
Comfort Ratio:
27.74
Capsize Screening:
1.78
S-Number:
1.74
Notes
Based on and very similar to the DAVIDSON 28, (mostly built in New Zealand).
