ALERION EXPRESS 20
Built by Tillotson Pearson Inc, (USA)
• Designed by Carl Schumacher
General Information
Hull Type:
Fin w/bulb & spade rudder
Rigging Type:
Fractional Sloop
Construction:
FG
First Built:
1996
Number Built:
45
Dimensions
Length Overall (LOA):
6.10 m
Length Waterline (LWL):
5.21 m
Beam:
2.08 m
Draft (Max):
1.07 m
Max Height:
9.35 m
Weight & Ballast
Displacement:
862 kg
Ballast:
354 kg
Sail Plan
Sail Area (reported):
20.44 m²
Engine & Systems
Performance Ratios
Hull Speed:
5.54 knots
SA/Displacement (Reported):
23.00
Ballast/Disp Ratio:
41.05%
Displacement/Length:
170.23
Comfort Ratio:
12.64
Capsize Screening:
2.21
Notes
AKA Alerion 20.
