CATALINA 400
Built by Catalina Yachts (US)
• Designed by Frank Douglas/Gerry Douglas
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Fin w/bulb & spade rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1994
Dimensions
Length Overall (LOA):
12.34 m
Length Waterline (LWL):
10.62 m
Beam:
4.11 m
Draft (Max):
2.06 m
Weight & Ballast
Displacement:
8,165 kg
Ballast:
3,266 kg
Sail Plan
Foresail Area:
37.92 m²
Mainsail Area:
37.11 m²
Total Sail Area (calculated):
75.03 m²
Sail Area (reported):
75.07 m²
I (Fore Triangle Height):
16.05 m
J (Fore Triangle Base):
4.72 m
P (Mainsail Hoist):
14.33 m
E (Boom Length):
5.18 m
Engine & Systems
Engine Type:
Diesel
Engine Power:
42 HP
Performance Ratios
Hull Speed:
7.91 knots
SA/Displacement (Calculated):
18.51
SA/Displacement (Reported):
18.89
Ballast/Disp Ratio:
40.00%
Displacement/Length:
190.18
Comfort Ratio:
23.79
Capsize Screening:
2.06
S-Number:
3.05
Notes
Wing keel draft: 5 ft / 1.52 m
