CATALINA 25
Built by Catalina Yachts (USA)
• Designed by Frank Butler
General Information
Hull Type:
Fin w/transom hung rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1978
Last Built:
1994
Number Built:
5866
Dimensions
Length Overall (LOA):
7.62 m
Length Waterline (LWL):
6.76 m
Beam:
2.44 m
Draft (Max):
1.22 m
Max Height:
9.14 m
Weight & Ballast
Displacement:
2,064 kg
Ballast:
862 kg
Sail Plan
Foresail Area:
14.14 m²
Mainsail Area:
10.97 m²
Total Sail Area (calculated):
25.11 m²
Sail Area (reported):
25.08 m²
I (Fore Triangle Height):
8.84 m
J (Fore Triangle Base):
3.20 m
P (Mainsail Hoist):
7.52 m
E (Boom Length):
2.92 m
Engine & Systems
Performance Ratios
Hull Speed:
6.31 knots
SA/Displacement (Calculated):
15.50
SA/Displacement (Reported):
15.78
Ballast/Disp Ratio:
41.76%
Displacement/Length:
186.41
Comfort Ratio:
19.14
Capsize Screening:
1.93
S-Number:
2.72
Notes
The most popular sailboat (in this size range) ever built in the US.
