CATALAC 10M
Built by Tom Lack Catamarans/Hythe Marine Services (UK)
• Designed by Tom Lack/J. Winterbotom
General Information
Hull Type:
Catamaran (no boards/asym.)
Rigging Type:
Masthead Sloop
Construction:
FG (solid)
First Built:
1984
Last Built:
1988
Number Built:
45
Dimensions
Length Overall (LOA):
10.26 m
Length Waterline (LWL):
8.23 m
Beam:
4.65 m
Draft (Max):
0.84 m
Max Height:
13.79 m
Weight & Ballast
Displacement:
5,579 kg
Sail Plan
Sail Area (reported):
57.23 m²
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel X 2
Fuel Capacity:
114 L
Water Capacity:
530 L
Performance Ratios
SA/Displacement (Reported):
18.56
Displacement/Length:
278.98
Notes
Also called CATALAC 34.
