CARTER 35
• Designed by Dick Carter
General Information
Hull Type:
Swing Keel
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1982
Dimensions
Length Overall (LOA):
10.57 m
Length Waterline (LWL):
8.48 m
Beam:
3.35 m
Draft (Max):
1.83 m
Draft (Min):
0.53 m
Weight & Ballast
Displacement:
4,218 kg
Ballast:
2,177 kg
Sail Plan
Foresail Area:
26.92 m²
Mainsail Area:
18.04 m²
Total Sail Area (calculated):
44.96 m²
Sail Area (reported):
54.35 m²
I (Fore Triangle Height):
12.62 m
J (Fore Triangle Base):
4.27 m
P (Mainsail Hoist):
10.76 m
E (Boom Length):
3.35 m
Engine & Systems
Performance Ratios
Hull Speed:
7.07 knots
SA/Displacement (Calculated):
17.22
SA/Displacement (Reported):
21.24
Ballast/Disp Ratio:
51.61%
Displacement/Length:
192.62
Comfort Ratio:
19.73
Capsize Screening:
2.10
S-Number:
2.86
Notes
Also available with the 'Luna rig'.
