CAPRI 30 (CHRIS-CRAFT)
Built by Chris-Craft (USA)
• Designed by Sparkman & Stephens
General Information
Hull Type:
Keel/Cbrd.
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1964
Dimensions
Length Overall (LOA):
9.14 m
Length Waterline (LWL):
7.62 m
Beam:
2.95 m
Draft (Max):
2.80 m
Draft (Min):
1.14 m
Max Height:
13.08 m
Weight & Ballast
Displacement:
5,325 kg
Ballast:
1,814 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
21.55 m²
Mainsail Area:
22.44 m²
Total Sail Area (calculated):
43.99 m²
Sail Area (reported):
44.04 m²
I (Fore Triangle Height):
12.19 m
J (Fore Triangle Base):
3.54 m
P (Mainsail Hoist):
10.52 m
E (Boom Length):
4.27 m
Engine & Systems
Engine Make:
Gray Marine
Engine Type:
Gas
Engine Model:
Sea Scout
Engine Power:
25 HP
Fuel Capacity:
76 L
Water Capacity:
121 L
Performance Ratios
Hull Speed:
6.70 knots
SA/Displacement (Calculated):
14.43
SA/Displacement (Reported):
14.73
Ballast/Disp Ratio:
34.07%
Displacement/Length:
335.43
Comfort Ratio:
33.33
Capsize Screening:
1.70
S-Number:
1.34
Notes
S&S Design# 1760.
