CAPE CUTTER 19
• Designed by Dudley Dix
General Information
Hull Type:
Centerboard (Trunk)
Rigging Type:
Gaff Head Cutter
Construction:
FG
First Built:
1998
Dimensions
Length Overall (LOA):
7.20 m
Length Waterline (LWL):
5.50 m
Beam:
2.20 m
Draft (Max):
1.22 m
Draft (Min):
0.45 m
Weight & Ballast
Displacement:
1,150 kg
Ballast:
400 kg
Sail Plan
Engine & Systems
Performance Ratios
Hull Speed:
5.69 knots
Ballast/Disp Ratio:
34.79%
Displacement/Length:
192.76
Comfort Ratio:
14.27
Capsize Screening:
2.12
Notes
LOD = 5.8m / 19.03 ft.
