CALIBER 40 LRC
Built by Caliber Yachts (USA)
• Designed by Michael McCreary
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Cutter
Construction:
FG
First Built:
1995
Dimensions
Length Overall (LOA):
12.47 m
Length Waterline (LWL):
9.91 m
Beam:
3.86 m
Draft (Max):
1.55 m
Weight & Ballast
Displacement:
9,798 kg
Ballast:
4,309 kg
Sail Plan
Foresail Area:
40.46 m²
Mainsail Area:
28.16 m²
Total Sail Area (calculated):
68.62 m²
Sail Area (reported):
68.66 m²
I (Fore Triangle Height):
15.39 m
J (Fore Triangle Base):
5.26 m
P (Mainsail Hoist):
13.94 m
E (Boom Length):
4.04 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Model:
4JH3 (B)E
Engine Power:
56 HP
Fuel Capacity:
803 L
Water Capacity:
678 L
Performance Ratios
Hull Speed:
7.64 knots
SA/Displacement (Calculated):
14.99
SA/Displacement (Reported):
15.30
Ballast/Disp Ratio:
43.98%
Displacement/Length:
280.90
Comfort Ratio:
32.39
Capsize Screening:
1.82
S-Number:
1.75
Notes
Original information indicates 179 gal / 677.6 liter water tank. Current brochures show 165 gal / 624.6 liter water tank.
