CAL 30
Built by Jensen Marine (USA)
• Designed by Lapworth
General Information
Hull Type:
Fin Keel
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1961
Last Built:
1967
Number Built:
123
Dimensions
Length Overall (LOA):
9.14 m
Length Waterline (LWL):
7.47 m
Beam:
3.05 m
Draft (Max):
1.37 m
Weight & Ballast
Displacement:
4,354 kg
Ballast:
1,588 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
19.51 m²
Mainsail Area:
19.51 m²
Total Sail Area (calculated):
39.02 m²
Sail Area (reported):
39.02 m²
I (Fore Triangle Height):
10.67 m
J (Fore Triangle Base):
3.66 m
P (Mainsail Hoist):
9.14 m
E (Boom Length):
4.27 m
Engine & Systems
Engine Make:
Universal
Engine Type:
Gas
Engine Model:
Atomic 4
Fuel Capacity:
76 L
Water Capacity:
95 L
Performance Ratios
Hull Speed:
6.63 knots
SA/Displacement (Calculated):
14.63
SA/Displacement (Reported):
14.93
Ballast/Disp Ratio:
36.46%
Displacement/Length:
291.42
Comfort Ratio:
26.42
Capsize Screening:
1.89
S-Number:
1.64
Notes
Alternate tall rig:
