CAL 29
Built by Jensen Marine (USA)
• Designed by William Lapworth
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1968
Last Built:
1974
Number Built:
624
Dimensions
Length Overall (LOA):
8.84 m
Length Waterline (LWL):
7.32 m
Beam:
2.82 m
Draft (Max):
1.37 m
Max Height:
12.50 m
Weight & Ballast
Displacement:
3,629 kg
Ballast:
1,520 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
21.19 m²
Mainsail Area:
18.02 m²
Total Sail Area (calculated):
39.21 m²
Sail Area (reported):
39.21 m²
I (Fore Triangle Height):
11.28 m
J (Fore Triangle Base):
3.76 m
P (Mainsail Hoist):
9.65 m
E (Boom Length):
3.73 m
Engine & Systems
Engine Make:
Universal
Engine Type:
Gas
Engine Model:
Atomic 4
Engine Power:
30 HP
Fuel Capacity:
76 L
Water Capacity:
76 L
Performance Ratios
Hull Speed:
6.56 knots
SA/Displacement (Calculated):
16.60
SA/Displacement (Reported):
16.93
Ballast/Disp Ratio:
41.88%
Displacement/Length:
258.35
Comfort Ratio:
25.04
Capsize Screening:
1.85
S-Number:
2.09
Notes
The CAL 29 was one of this builders most popular models.
