CAL 2-46
Built by Jensen Marine (USA)
• Designed by C. William Lapworth
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1971
Last Built:
1975
Number Built:
129
Dimensions
Length Overall (LOA):
13.87 m
Length Waterline (LWL):
11.43 m
Beam:
3.81 m
Draft (Max):
1.52 m
Weight & Ballast
Displacement:
13,608 kg
Ballast:
3,629 kg
Sail Plan
Foresail Area:
40.13 m²
Mainsail Area:
32.43 m²
Total Sail Area (calculated):
72.56 m²
Sail Area (reported):
72.56 m²
I (Fore Triangle Height):
14.63 m
J (Fore Triangle Base):
5.49 m
P (Mainsail Hoist):
12.22 m
E (Boom Length):
5.31 m
Engine & Systems
Engine Make:
Perkins
Engine Type:
Diesel
Fuel Capacity:
1,022 L
Water Capacity:
644 L
Performance Ratios
Hull Speed:
8.21 knots
SA/Displacement (Calculated):
12.73
SA/Displacement (Reported):
13.00
Ballast/Disp Ratio:
26.67%
Displacement/Length:
253.97
Comfort Ratio:
40.21
Capsize Screening:
1.61
S-Number:
1.73
Notes
A development from the earlier CAL 46 MS (CAL CRUISING 46). The differences between this and the earlier version:
