ALBIN 57
Built by Albin Marine (SWE)
• Designed by Rolf Magnusson
General Information
Hull Type:
Swing Keel
Rigging Type:
Fractional Sloop
Construction:
FG
First Built:
1977
Last Built:
1981
Number Built:
400
Dimensions
Length Overall (LOA):
5.74 m
Length Waterline (LWL):
5.00 m
Beam:
2.41 m
Draft (Max):
1.30 m
Draft (Min):
0.60 m
Weight & Ballast
Displacement:
800 kg
Ballast:
255 kg
Sail Plan
Foresail Area:
7.48 m²
Mainsail Area:
8.04 m²
Total Sail Area (calculated):
15.52 m²
Sail Area (reported):
15.51 m²
I (Fore Triangle Height):
6.65 m
J (Fore Triangle Base):
2.25 m
P (Mainsail Hoist):
6.70 m
E (Boom Length):
2.40 m
Engine & Systems
Performance Ratios
Hull Speed:
5.43 knots
SA/Displacement (Calculated):
18.01
SA/Displacement (Reported):
18.34
Ballast/Disp Ratio:
31.86%
Displacement/Length:
178.53
Comfort Ratio:
10.12
Capsize Screening:
2.62
S-Number:
3.14
