JUNIOR HOLIDAY 24

Built by E. G. van de Stadt (NED) • Designed by E. G. van de Stadt
Sign in to add to Favorites
JUNIOR HOLIDAY 24 - Drawing

Help improve this yacht's listing by uploading your own images.

No files selected Max 5 images, 5MB each (JPG, PNG, WebP)

General Information

Hull Type: Fin w/spade rudder
Rigging Type: Fractional Sloop
First Built: 1954

Dimensions

Length Overall (LOA): 7.52 m
Length Waterline (LWL): 5.43 m
Beam: 2.01 m
Draft (Max): 1.01 m

Weight & Ballast

Displacement: 1,098 kg
Ballast: 426 kg
Ballast Type: Iron

Sail Plan

Sail Area (reported): 24.25 m²

Engine & Systems

Engine Make: Palmer
Engine Type: Gas
Engine Power: 8 HP

Performance Ratios

Hull Speed: 5.66 knots
SA/Displacement (Reported): 23.22
Ballast/Disp Ratio: 38.84%
Displacement/Length: 190.60
Comfort Ratio: 15.28
Capsize Screening: 1.96
Immersion: 419.20 cm/kg

Notes

Similar to HOLIDAY 24 SAILOR.
