C&C 29-2
Built by C&C Yachts
• Designed by Cuthbertson & Cassian
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1983
Last Built:
1986
Number Built:
400
Dimensions
Length Overall (LOA):
8.69 m
Length Waterline (LWL):
6.81 m
Beam:
2.87 m
Draft (Max):
1.62 m
Weight & Ballast
Displacement:
3,039 kg
Ballast:
1,225 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
20.26 m²
Mainsail Area:
16.40 m²
Total Sail Area (calculated):
36.66 m²
Sail Area (reported):
36.79 m²
I (Fore Triangle Height):
11.73 m
J (Fore Triangle Base):
3.45 m
P (Mainsail Hoist):
10.13 m
E (Boom Length):
3.24 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Model:
2GMF
Fuel Capacity:
76 L
Water Capacity:
121 L
Performance Ratios
Hull Speed:
6.33 knots
SA/Displacement (Calculated):
17.48
SA/Displacement (Reported):
17.88
Ballast/Disp Ratio:
40.30%
Displacement/Length:
268.63
Comfort Ratio:
21.59
Capsize Screening:
2.00
S-Number:
2.07
Notes
Shoal draft: 4.0'.
